0034DPSA31A-P


Motor Model Details
Model Number 0034DPSA31A-P
Multiplier Symbol MCTDPP
Weight 90 lbs
Technical Data
Data Package Download

60 Hertz Data
HP 3
Frame 182T
FORM DBK1
TYPE IK
Model Number 0034DPSA31A-P
NOM. EFF. 89.5
VOLTS 230/460
Enclosure ODP
SF 1.15
AMB 40 C
Min. Eff.
Frequency 60 Hz
FLAMPS 4-Aug
NEMA B
Code K
kW
PF 83
S.RPM 1800
FLRPM 1760
Insul Class F
Duty CONT.
Serial No.
Amperage
Locked Rotor: 32
Torques
Full Load (lb-ft): 9
Locked Rotor: 215
Break Down: 360
Bearings
Drive End: 6207ZZ
Opposite Drive End: 6206ZZ
Efficiency (%)
Full Load: 89.5
3/4 Load: 89.7
1/2 Load: 88.2
Power Factor (%)
Full Load: 83
3/4 Load: 65.5
1/2 Load: 89.7
