0506DPSA31A-P


Motor Model Details
Model Number 0506DPSA31A-P
Multiplier Symbol MCTDPP
Weight 743 lbs
Technical Data
Data Package Download

60 Hertz Data
HP 50
Frame 365T
FORM VBK1
TYPE TIKK
Model Number 0506DPSA31A-P
NOM. EFF. 94.1
VOLTS 230/460
Enclosure ODP
SF 1.15
AMB 40 C
Min. Eff.
Frequency 60 Hz
FLAMPS 124/62
NEMA B
Code H
kW
PF 81
S.RPM 1200
FLRPM 1180
Insul Class F
Duty CONT.
Serial No.
Amperage
Locked Rotor: 362.5
Torques
Full Load (lb-ft): 222.5
Locked Rotor: 200
Break Down: 290
Bearings
Drive End: 6314
Opposite Drive End: 6313
Efficiency (%)
Full Load: 94.1
3/4 Load: 94.3
1/2 Load: 93.8
Power Factor (%)
Full Load: 81
3/4 Load: 70
1/2 Load: 94.3
