0152DPSC31A-P


Motor Model Details
Model Number 0152DPSC31A-P
Multiplier Symbol MCTDPP
Weight 183 lbs
Technical Data
Data Package Download

60 Hertz Data
HP 15
Frame 215T
FORM DCK1
TYPE IKK
Model Number 0152DPSC31A-P
NOM. EFF. 90.2
VOLTS 575
Enclosure ODP
SF 1.15
AMB 40 C
Min. Eff.
Frequency 60 Hz
FLAMPS 14.7
NEMA B
Code H
kW
PF 85
S.RPM 3600
FLRPM 3500
Insul Class F
Duty CONT.
Serial No.
Amperage
Locked Rotor: 93.2
Torques
Full Load (lb-ft): 22.509
Locked Rotor: 210
Break Down: 260
Bearings
Drive End: 6308ZZ
Opposite Drive End: 6208ZZ
Efficiency (%)
Full Load: 90.2
3/4 Load: 90.8
1/2 Load: 89.9
Power Factor (%)
Full Load: 85
3/4 Load: 77
1/2 Load: 90.8
