0204DPSA31A-P


Motor Model Details
Model Number 0204DPSA31A-P
Multiplier Symbol MCTDPP
Weight 300 lbs
Technical Data
Data Package Download

60 Hertz Data
HP 20
Frame 256T
FORM DBK1
TYPE TIKK
Model Number 0204DPSA31A-P
NOM. EFF. 93
VOLTS 230/460
Enclosure ODP
SF 1.15
AMB 40 C
Min. Eff.
Frequency 60 Hz
FLAMPS 50/25
NEMA B
Code G
kW
PF 82.5
S.RPM 1800
FLRPM 1765
Insul Class F
Duty CONT.
Serial No.
Amperage
Locked Rotor: 145
Torques
Full Load (lb-ft): 59.5
Locked Rotor: 265
Break Down: 255
Bearings
Drive End: 6310ZZ
Opposite Drive End: 6208ZZ
Efficiency (%)
Full Load: 93
3/4 Load: 93.2
1/2 Load: 92.8
Power Factor (%)
Full Load: 82.5
3/4 Load: 70
1/2 Load: 93.2
