0206DPSA31A-P


Motor Model Details
Model Number 0206DPSA31A-P
Multiplier Symbol MCTDPP
Weight 373 lbs
Technical Data
Data Package Download

60 Hertz Data
HP 20
Frame 286T
FORM VBK1
TYPE TIKK
Model Number 0206DPSA31A-P
NOM. EFF. 92.4
VOLTS 230/460
Enclosure ODP
SF 1.15
AMB 40 C
Min. Eff.
Frequency 60 Hz
FLAMPS 51.6/25.8
NEMA B
Code F
kW
PF 84
S.RPM 1200
FLRPM 1170
Insul Class F
Duty CONT.
Serial No.
Amperage
Locked Rotor: 145
Torques
Full Load (lb-ft): 89.8
Locked Rotor: 140
Break Down: 200
Bearings
Drive End: 6312ZZ
Opposite Drive End: 6211ZZ
Efficiency (%)
Full Load: 92.4
3/4 Load: 92.5
1/2 Load: 92.2
Power Factor (%)
Full Load: 84
3/4 Load: 74.5
1/2 Load: 92.5
