B1006VLF4OSH


Motor Model Details
Model Number B1006VLF4OSH
Multiplier Symbol MXTDPP
Weight 1406 lbs
Technical Data
Data Package Download

60 Hertz Data
HP 100
Frame 444T
FORM VBK1
TYPE TKKH
Model Number B1006VLF4OSH
NOM. EFF. 95.4
VOLTS 575
Enclosure ODP
SF 1.15
AMB 40 C
Min. Eff. 94.5
Frequency 60 Hz
FLAMPS 97
NEMA B
Code F
kW 74.6
PF 81.1
S.RPM 1200
FLRPM 1188
Insul Class F
Duty CONT
Serial No.
Amperage
Locked Rotor: 560
Torques
Full Load (lb-ft): 442
Locked Rotor: 170
Break Down: 240
Bearings
Drive End: NU318C3
Opposite Drive End: 6318C3
Efficiency (%)
Full Load: 95.5
3/4 Load: 95.9
1/2 Load: 95.5
Power Factor (%)
Full Load: 81.1
3/4 Load: 70
1/2 Load: 77.9
