B2506VLG3OMH


Motor Model Details
Model Number B2506VLG3OMH
Multiplier Symbol MXTDPP
Weight 2072 lbs
Technical Data
Data Package Download

60 Hertz Data
HP 250
Frame 505US
FORM VCK1
TYPE TKKH
Model Number B2506VLG3OMH
NOM. EFF. 95.8
VOLTS 575
Enclosure ODP
SF 1.15
AMB 40 C
Min. Eff. 95
Frequency 60 Hz
FLAMPS 230
NEMA B
Code G
kW 186.4
PF 85.1
S.RPM 1200
FLRPM 1184
Insul Class F
Duty CONT
Serial No.
Amperage
Locked Rotor: 1460
Torques
Full Load (lb-ft): 1109
Locked Rotor: 185
Break Down: 290
Bearings
Drive End: 6320C3
Opposite Drive End: 6320C3
Efficiency (%)
Full Load: 95.9
3/4 Load: 96.4
1/2 Load: 96.3
Power Factor (%)
Full Load: 85.1
3/4 Load: 74.7
1/2 Load: 82.1
