4400F3F800XA


UPS Model Details
Model Number 4400F3F800XA
Capacity (kVA/kW) 80.0/72KW
TopologyTrue On-Line, Double-Conversion

Input

Standard Voltage 208V
Optional Voltage '200,220,230,240,380,400,415,480,600V
Phase 3PH
Frequency 50/60Hz
Power Factor 0.98
DC Voltage 288V

Output

Standard Voltage 208V
Optional Voltage '200,220,230,240,380,400,415,480,600V
Phase 3PH
Frequency 50/60HZ
Power Factor 0.9
Voltage THD <3% THD at full linear load
Overload Capacity 109% Continuous, 110-124% for 6 Minutes, 125-149% for 90 Seconds, 150% for 30 Seconds;

Environment

Temperature Range 32° to 104°F (0° to 40°C)
Humidity 0-95%, non-condensing
Heat Rejection 24,297 BTU/Hr
Full-Load Efficiency 0.92
Altitude 3300 ft (1000 m) above sea level
Audible Noise 63dBA @ 1 m Typical

Dimensions

Dimensions 32.1" W x 37.2" D x 73.8" H
Weight 1550lbs.
Color DuPont O’Brien Black
Monitoring Touchscreen Operator Interface, UPS Status N/O Dry Contacts, RS232C Interface (Optional RemotEye® 4 Intelligent Monitoring System)
Options Internal Transformer, Dual-Input Feed, RemotEye® 4 Intelligent Monitoring System, Remote Status Alarm Panel, External Matching & Non-Matching Battery Cabinets, Matching MBS/Transformer/Distribution Cabinets
Features Low Profile 3 Phase UPS Systems, Internal Transformer for 200-600V Input or Output Operation, OSHPD Certification for UPS and Ancillary Gear
Standards UL 1778, CUL, ISO9001, ISO14001:2004, ANSI C62.41 (IEEE 587), NEMA/PET-1993, CE, IBC, & CBC (OSHPD)
Warranty 3-Year On-Site Warranty;See Toshiba Warranty Policy for Full Details
Service 24-Hour, 365-Day Technical Support: 1-877-867-8773
