Model Number | T90S3S75KS6XSN |
Capacity (kVA/kW) | 750.0/750KW |
Topology | True On-Line, Double-Conversion |
Standard Voltage | 480V |
Optional Voltage | N/A |
Phase | 3PH |
Frequency | 60HZ |
Power Factor | 0.99 |
DC Voltage | 480V |
Standard Voltage | 480V |
Optional Voltage | N/A |
Phase | 3PH |
Frequency | 60HZ |
Power Factor | 1 |
Voltage THD | <2% at 100% Linear Load, <5% at 100% non-linear load |
Overload Capacity | Inverter: 125% for 10 Minutes, 150% for 60 Seconds, Bypass: 500% for 1 cycle |
Temperature Range | 32° to 104°F (0° to 40°C) |
Humidity | 5% to 95% Non-Condensing |
Heat Rejection | 79.2 kBTU/Hour |
Full-Load Efficiency | 0.97 |
Altitude | 7380 ft. (2250 m) Maximum Without Derating |
Audible Noise | 71dBA @ 1 m Typical |
Dimensions | 90.6” W x 32.8” D x 80.7” H |
Weight | 4,250 lbs. (1497 kg) |
Color | Munsell N1.5 (Black) |
Monitoring | Touchscreen Operator Interface, UPS Status N/O Dry Contacts, RS232 Port, Optional RemotEye® 4 Intelligent Monitoring System |
Options | Dual-Input Feed, RemotEye® 4 Intelligent Monitoring System, Remote Status Alarm Panel, Air Filters, Spare Parts Kits |
Features | Digital Signal Processor (DSP) Control, Fully Digital IGBT Converter & Inverter, High Efficiency Over Wide Load Range, Transformer-Less Design, N+1 & N+N (Up to Eight in Parallel) Capability, Dual-Input Feed, Electronic Battery Isolation, RS232 and Dry Contact Interface, Small Footprint, & Lightweight Design, Energy Star® Certified |
Standards | UL/CUL 1778 Listed, ISO 9001, ISO 14001, ANSI C62.41 (IEEE 587), IEC 62040-2 Cat. C3, OSHPD, IBC Code ICC-ES AC156, (CBC) Section 1708A. |
Warranty | 3-Year On-Site Warranty; See Toshiba Warranty Policy for Full Details |
Service | 24-Hour, 365-Day Technical Support: 1-877-867-8773 |
