The Toshiba G9400 Series Uninterruptible Power System (UPS) brings the time-proven design and industry leading efficiency, reliability, and performance of the G9000 Series to a new level. The G9400 Series features the latest generation of advanced Carrier Stored Trench Bi-Polar Transistor (CSTBT) IGBT technology, the “engine” of the UPS. The G9400 technology allows for high power density in a small footprint and 97% on-line efficiency at various loads making it ideal for large Colocation or Hyper-Scale Data Centers around the globe.
Features:
- Available in 60Hz / 480V / 1200kVA, 1600kVA, and 2000kVA models
- For global applications, also available in 60 / 50Hz / 380 to 415V / 1050kVA, 1400kVA, and 1750kVA models
- Unique parallel power module design allows for built-in redundancy and continuous power quality protection to loads
- Easily parallel-able for up to six units for capacity or any N+x critical power tier level redundancy with built in parallel monitoring in each UPS, eliminating costly intelligence scheme or monitoring requirements in the parallel gear
- Able to perform a self-load test, which acts as a unique alternative to using costly external load banks during UPS startup and preventative maintenance
- Remote monitoring available through Toshiba’s state-of-the-art RemotEye®4 secure IoT multi-protocol card
- Compatible with a variety of the latest Energy Storage Systems (ESS) including VRLA, wet cell, NiCad, Nickel Zinc, or Toshiba’s SCiB™ Lithium Ion batteries
- Three-Year Warranty for Lower Cost of Ownership
