Toshiba's heavy duty S15 adjustable speed drive is a compact and high performance drive designed for controlling a wide range of variable and constant torque applications. This micro-drive is capable of working with permanent magnet (PM) motors, which allows for greater flexibility in selecting a motor for an application and optimizes energy savings. A robust design allows the S15 to operate in extreme temperatures and environments. In addition, the S15 features advanced technologies, and an expanded PID control allows a greater level of precise control and operation of difficult level control applications. No other micro-drive delivers such reliable and extreme performance with extensive capabilities at such a competitive cost.
The S15 is one of the most compact drives available on the market. This drive makes a fantastic choice if footprint or price is an issue for the end user as it still offers heavy duty ratings through a 150%/60s overload rating and up to 60C ambient temperature.
Model |
VAC |
HP (HD) |
FLA (HD) |
|---|---|---|---|
| VFS15-2004PM-W1 | 230 | 0.5 | 3.3 |
| VFS15-2015PM-W1 | 230 | 2.0 | 8.0 |
| VFS15-2022PM-W1 | 230 | 3.0 | 11.0 |
| VFS15-2037PM-W1 | 230 | 5.0 | 17.5 |
| VFS15-2075PM-W1 | 230 | 10.0 | 33.0 |
| VFS15-2110PM-W1 | 230 | 15.0 | 54.0 |
| VFS15S-2002PL-W1 | 230 Single-Phase | 0.25 | 1.5 |
| VFS15S-2004PL-W1 | 230 Single-Phase | 0.5 | 3.3 |
| VFS15S-2015PL-W1 | 230 Single-Phase | 2.0 | 8.0 |
| VFS15S-2022PL-W1 | 230 Single-Phase | 3.0 | 11.0 |
| VFS15-4007PL1-W1 | 460 | 1.0 | 2.3 |
| VFS15-4022PL1-W1 | 460 | 3.0 | 5.5 |
| VFS15-4037PL1-W1 | 460 | 5.0 | 9.5 |
| VFS15-4075PL-W1 | 460 | 10.0 | 17.0 |
| VFS15-4150PL-W1 | 460 | 20.0 | 33.0 |
| VFS15-6015P-W1 | 600 | 2.0 | 2.7 |
| VFS15-6055P-W1 | 600 | 7.5 | 9.0 |
| VFS15-6150P-W1 | 600 | 20.0 | 22.0 |
| VFS15-2007PM-W1 | 230 | 1.0 | 4.8 |
| VFS15-4004PL1-W1 | 460 | 0.5 | 1.5 |
| VFS15-4015PL1-W1 | 460 | 2.0 | 4.1 |
| VFS15-6110P-W1 | 600 | 15.0 | 17.0 |
| VFS15-6037P-W1 | 600 | 5.0 | 6.1 |
| VFS15-2055PM-W1 | 230 | 7.5 | 27.5 |
| VFS15-2150PM-W1 | 230 | 20.0 | 66.0 |
| VFS15S-2007PL-W1 | 230 Single-Phase | 1.0 | 4.8 |
| VFS15-4055PL-W1 | 460 | 7.5 | 14.3 |
| VFS15-4110PL-W1 | 460 | 15.0 | 27.7 |
| VFS15-6022P-W1 | 600 | 3.0 | 3.9 |
| VFS15-6075P-W1 | 600 | 10.0 | 11.0 |
